Vertical Plhaub thiab Tube Condenser
Nominal txoj kab uas hla: 159-1000 mm
Tus naj npawb ntawm cov raj xa mus: 1 txog 2
Condensing cheeb tsam: 1.5 txog 1500 m² (tube ntev 1.5 txog 6 m)
Nominal siab: 0.25-2.5 MPa
Tube sab ntws tus nqi (ntawm 0.5 m / s): 7.38 txog 501.74 m³ / h
- Khoom Taw qhia
Peb muaj 30 xyoo keeb kwm
Peb lub tuam txhab yog lub chaw tsim khoom kub exchanger nrog ntau tshaj 30 xyoo keeb kwm. Peb tau dhau ISO9001, ISO14001 thiab ISO18001 ntawv pov thawj. Cov neeg siv khoom nug peb, "Koj puas muaj ib tus neeg rau kev pabcuam tomqab muag?" Peb teb tias, "Yog, peb ua." Peb pab neeg tom qab kev muag khoom muab kev taw qhia ntawm qhov chaw teeb tsa thiab kev xa khoom xa tuaj. Vertical plhaub thiab raj condenser yog ntsia vertically. Nws qhov chaw hauv pem teb yog me dua li ib chav kab rov tav. Chav nkag los ntawm sab saum toj. Nws condenses sab nraum cov hlab. Cov kua condensate ntws los ntawm lub ntiajteb txawj nqus thiab tawm hauv qab. Cov dej txias nkag mus rau hauv cov hlab ntsha. Nws tuaj yeem ntws los ntawm sab saum toj mus rau hauv qab lossis hauv qab mus rau saum. Peb tuaj yeem nruab baffles hauv lub plhaub los txhim kho kev sib xyaw ua ke.
Peb xa cov qauv qauv hauv 20 hnub
Cov neeg siv khoom nug peb, "Lub sijhawm tsim khoom ib txwm rau cov khoom lag luam yog dab tsi?" Peb teb, "20 hnub." Rau ib yam khoom, lub sij hawm ntau lawm yog 20 hnub. Cov khoom no yog nrov heev nyob rau hauv loj cia txias txias tshuab thiab central HVAC chillers. Ammonia tub yees tshuab hauv qhov txias cia feem ntau siv lub plhaub ntsug thiab lub raj condenser vim nws siv qhov chaw me me hauv pem teb thiab tuaj yeem tso rau sab nraum zoov. Cov roj thiab tshuaj lom neeg kev lag luam kuj tseem siv nws kom rov qab tau cov pa condensed. Piv txwv li, dej vapor los ntawm sab saum toj ntawm lub distillation ntauwd nkag mus rau hauv lub condenser ntsug thiab ua condensate rau rov qab. Hauv kev ua zaub mov, chav los ntawm sterilizers yuav tsum tau condensed ua ntej tso tawm. Peb muaj cov neeg siv khoom txias cia hauv Pakistan. Lawv qhov txias txias muaj peev xwm ua kom txias ntawm 500 kW. Peb muab cov khoom lag luam nrog 150 m² ntawm condensing cheeb tsam. Kev teeb tsa siv tsuas yog 2 square metres ntawm thaj chaw hauv pem teb. Qhov ntawd cawm tau ntau chav.
Peb txhawb cov qauv kev cai uas tsis yog qauv
Cov neeg siv khoom nug peb, "Koj puas tuaj yeem tsim los ntawm peb cov duab kos duab lossis qauv qauv?" Peb teb tias, "Yog, peb ua tau." Peb txhawb cov qauv kev cai uas tsis yog qauv. Yam tsawg kawg nkaus kom muaj nuj nqis yog ib chav tsev. Export packing siv fumigated ntoo thawv. Vertical units yog siab, yog li peb ntxiv kev txhawb nqa ntxiv thiab kho. Peb yuav kev pov hwm hauv tsev los ntawm peb lub Hoobkas mus rau qhov chaw nres nkoj. Peb ntseeg hais tias yog tias koj lub Hoobkas qhov chaw raug txwv, lub plhaub ntsug thiab lub raj condenser yog qhov zoo tshaj plaws kom txuag tau qhov chaw hauv pem teb.
Cov ntaub ntawv tseem ceeb
|
Parameter |
Tus nqi |
|
Nominal txoj kab uas hla |
159-1000 hli |
|
Tus naj npawb ntawm lub raj xa mus |
1 rau 2 |
|
Condensing cheeb tsam |
1.5 txog 1500 m² (tube ntev 1.5 txog 6 m) |
|
Nominal siab |
0.25-2.5MPa |
|
Tube sab ntws tus nqi (ntawm 0.5 m / s) |
7.38-501.74 m³ / h |
Cim npe nrov: Vertical plhaub thiab raj condenser, Tuam Tshoj ntsug plhaub thiab raj condenser manufacturers, lwm tus neeg, Hoobkas
